Potter PBA-1206 is a 6 in. (150 mm) vibrating bell for 120 VAC fire or general signaling circuits, part of the Potter PBA-AC series. It draws little current and gives a high sound output, and it mounts directly on a standard 4 in. square electrical box indoors or on a weatherproof back box outdoors.
Specifications
| Model / stock number |
PBA1206 / 1806120 |
| Gong size |
6 in. (150 mm) |
| Voltage |
120 VAC |
| Current (max.) |
0.05 A |
| Sound output at 10 ft (3 m) |
92 dB typical, 83 dB minimum (UL 464), 77 dB FM |
| Cover |
Steel, red powder coat |
| Base |
Non-corrosive composite |
| Termination |
4 No. 18 AWG stranded wires |
| Environment |
-40 °F to 150 °F (-40 °C to 66 °C); outdoor use requires a weatherproof back box |
| Service use |
NFPA 13, NFPA 72, local AHJ |
Installation notes
- Indoors, mount the bell directly to a standard 4 in. (101 mm) square electrical box
- Outdoors or in wet locations, use the BBK-1, HC-BB or GBBB weatherproof back box; a standard electrical box is not weatherproof
- Mount the mechanism with the striker pointing down, or the bell will not ring
- Install the top of the bell no less than 90 in. above the finished floor and not less than 6 in. below the ceiling
- With AC bells, terminate each extra wire separately after the last bell
Related models
The PBA-AC series also includes the 120 VAC PBA1208 (8 in.) and PBA12010 (10 in.) and the 24 VAC PBA246, PBA248 and PBA2410. The 8 in. and 10 in. sizes accept the optional bell guard bracket.
Documents
FAQ
Can the PBA-1206 be installed outdoors?
Yes, when it is mounted on a BBK-1, HC-BB or GBBB weatherproof back box. Indoors it mounts directly to a standard 4 in. square electrical box.
What voltage and current does it need?
The PBA-1206 is a 120 VAC bell with a maximum current of 0.05 A. For 24 VAC circuits, Potter offers the PBA246 in the same 6 in. size.
How loud is the 6 in. 120 VAC bell?
Potter rates it at 92 dB typical and 83 dB minimum at 10 ft (3 m), with an FM rating of 77 dB.
Which way should the bell be mounted?
The mechanism must be mounted with the striker pointing down. If it is installed striker up, the bell will not ring.
