Potter MR-101C/R is a multi-voltage control relay with a 10 A SPDT contact, supplied in an enclosure with a red cover. The red cover version is used in New York City and similar installations.
Relays can be used where local contacts are needed for system status, or remote contacts for switching electrical loads.
Features
- Energized from 24 V DC, 24 V AC, 120 V AC or 230 V AC by wiring to the matching input terminals; input range is 18 to 35 V DC or AC, 120 V AC or 230 V AC
- Red LED lights when the coil is energized, so an installed system can be checked without a meter
- DC control inputs are polarized
- Continuous duty at 24 V AC, 24 V DC or 120 V AC; not intended for continuous duty at 230 V AC
- UL recognized relay rated for 10,000,000 mechanical operations
- Suited to HVAC, temperature control, fire alarm, security, energy management and lighting control systems
Specifications
| Model |
MR-101C/R |
| Contact |
SPDT, 10 A |
| Control voltages |
24 V DC, 24 V AC, 120 V AC, 230 V AC |
| Mounting |
Enclosure mount, red cover |
| Height |
5.1 in |
| Width |
3.1 in |
| Depth |
2.5 in |
