Potter MPEX is the Federal Signal MPEX explosion-proof manual pull station for hazardous locations where flammable gases, vapors, combustible dusts or easily ignitable fibers are present.
A swing-up front cover exposes a pull-down ring that activates the alarm. The two-step action prevents accidental activation. The station is reset by depressing the shaft and returning the plate to its original position.
Specifications
| Hazardous locations |
Class I Div. 1 Groups C, D; Class II Div. 1 Groups E, F, G; Class III |
| Enclosure rating |
NEMA 7 (Groups C, D), NEMA 9 (Groups E, F, G) |
| Electrical |
120 VAC, 60 Hz, 6 A |
| Conduit |
Two 3/4 in. NPT feed-through openings |
| Material |
Copper-free cast aluminum |
| Finish |
Red textured powder epoxy |
| Operating temperature |
-31 to 104 °F |
| Dimensions |
6.4 x 3.1 x 4.1 in. |
| Shipping weight |
2.7 lb |
| Approvals |
UL, ULC and CSFM certified |
Installation notes
- Lift the cover and pull the ring down to activate
- Reset by depressing the shaft and returning the plate
- Ordering part number 1000548
Related models
- RMS-6T-EXP-WP: Potter die-cast explosion-proof and weatherproof pull station
Documents
FAQ
Where can the MPEX be installed?
In Class I, Division 1, Groups C and D; Class II, Division 1, Groups E, F and G; and Class III hazardous locations.
How is it activated?
Lift the swing-up cover and pull the ring down. The two-step action prevents accidental activation.
How is it reset?
Depress the shaft and return the plate to its original position.
What conduit does it take?
It has two 3/4 in. NPT feed-through conduit openings.
