Potter OSYSU-1 - The Fire Alarm Supplier

Roll over image to zoom in Click on image to zoom

OSYSU-1

Name: OSYSU-1
Availability: BackOrder

PotterSKU: OSYSU-1

Price:

$132.95 $159.54

Shipping calculated at checkout

Stock:

Sold Out - Call for Lead Time

Quantity:

Pickup available at Phoenix, AZ

Usually ready in 1 hour

Category: Supervisory Switches
Stock: 0 units - Call or Chat for Lead Time
Barcode (UPC): 785192021698
Weight: 2.3 lb
Brand: Potter

Potter OSYSU-1 OSYSU Series Outside Screw and Yoke Valve Supervisory Switch (Single Switch)

The OSYSU is used to monitor the open position of an OS&Y (outside screw and yoke) type gate valve. This device is available in two models; the OSYSU-1, containing one set of SPDT (Form C) contacts and the OSYSU-2, containing two sets of SPDT (Form C) contacts.

These switches mount conveniently to most OS&Y valves ranging in size from 2” to 12” (50mm to 300mm).

They will mount on some valves as small as ½” (12,5mm). The cover is held in place by two tamper resistant screws that require a special tool to remove. The tool is furnished with each device.

Features

NEMA 4X (IP 65) and 6P (IP 67)
-40º to 140º (-40ºC to 60ºC) operating temperature range
Visual Switch Indicators and Two conduit entrances
