Notifier SBB-C4R — CAB-4 Series backbox assembly, C size, three tiers, red.
Notifier CAB-4 Series cabinets house ONYX Series control panels and their chassis, and are sold in halves: one SBB backbox plus one DR locking door make a complete cabinet. The SBB-C4R is the backbox half only, three-tier C size, red. No door, battery plate or trim ring is included.
- C size, three tiers, red, fabricated from 16-gauge steel
- Weight 32.60 lb
- Backbox 24 in. W × 37-1/8 in. H × 5-5/32 in. D, with mounting holes 19-1/2 in. apart
- Knockouts positioned at numerous points to ease conduit entry
- Takes the optional BP2-4 battery plate when batteries or a power supply sit in the lower position
- Optional TR-C4 semi-flush trim ring, opening 24.062 in. W × 37.187 in. H
- Seismic certified with SEISKIT-CAB; UL and ULC Certified S635
Order the matching door separately: DR-C4R with window or DR-C4BR solid, both red. The tier count is the trap here, since SBB-A4R is one tier, SBB-B4R two, SBB-D4R four and SBB-AA4R a mini one-tier box with no battery compartment. SBB-C4 is the same box in black.
Need this model in another color? See Notifier SBB-C4 Backbox Assembly.
