Notifier NH-200 is a white, low-profile intelligent thermal sensor with a 135°F (57°C) fixed-temperature set point, for FlashScan applications. It is part of the NH-200 Series, the direct replacement for the NH-100 Series, and is used with ONYX Series and FireWarden fire alarm control panels where heat detection is required. Versions of the series are available for both FlashScan and CLIP applications.
Specifications
| Fixed temperature |
135°F (57°C) |
| Operating temperature |
-4°F to 100°F (-20°C to 38°C) |
| Humidity |
10% to 93% non-condensing |
| Spacing |
UL: 50 ft (15.24 m); FM: 25 x 25 ft (7.62 x 7.62 m) |
| Protocol |
FlashScan |
| Color |
White |
Features
- Rotary decimal address switches
- Dual LEDs for 360° visibility
- Low-profile design with low standby current
- Replaces the NH-100 Series
- Works with ONYX Series and FireWarden panels
- UL certified (S747); FM approved
