Notifier NFW-50 — FireWarden-50 intelligent addressable fire alarm control panel with built-in communicator. Discontinued, replaced by the NFW-50X or NFW-50XR.
The FireWarden-50 combines a fire alarm control panel and a digital alarm communicator/transmitter (DACT) on one circuit board. It supports up to 50 addressable devices in any combination of detectors and modules, so it fits applications previously served by conventional panels. The DACT reports system status to a central station over the public switched telephone network and allows remote programming with the PS-Tools upload/download utility.
Specifications
| Model |
NFW-50 (FireWarden-50) |
| Capacity |
Up to 50 addressable devices |
| Communicator |
On-board DACT |
| NACs |
Two, Style Z (Class A) or Style Y (Class B) |
| Relays |
Two programmable and one fixed trouble |
| Display |
80-character backlit LCD |
| History |
500 events |
| Strobe sync |
System Sensor, Wheelock, Gentex |
Replacement
- NFW-50X: FireWarden-50X, the current panel in the FireWarden Series with pre-installed communicator
- NFW-50XR: red version of the NFW-50X
Documents
FAQ
Is the NFW-50 still available?
No. The NFW-50 is discontinued and replaced by the NFW-50X or NFW-50XR.
How many devices does the FireWarden-50 support?
Up to 50 addressable devices in any combination of detectors or modules.
Does it have a built-in communicator?
Yes. The FACP and DACT are combined on one circuit board, reporting to a central station over the telephone network.
