Notifier N16E — INSPIRE Series intelligent fire alarm panel, one SLC loop, 10 in. touchscreen, black enclosure.
The N16E is the preconfigured member of the INSPIRE N16 family: display, power supply and first signaling line module already in the cabinet rather than built up card by card. It ships on the N16E persona, and a one-time N16-XUPG licence converts it to the larger N16x persona.
- 10 in. high definition colour touchscreen with customizable buttons
- One SLM-318 Signaling Line Module for 318 addressable points, expandable to three and 954 points
- Up to 159 detectors and 159 addressable modules per SLC loop
- 6.0 A power supply, four Class A/B outputs configurable as NACs, two configurable auxiliary outputs
- Backbox 19.12 × 18.12 × 5.47 in., 35 lb shipping weight, batteries to 26 AH inside
- CLSS Gateway connectivity and SWIFT wireless support
N16E-R is the same panel in a red enclosure. CPU-N16LD is the chassis-mounted equivalent for CAB-5 cabinets, CPU-N16LND drops the display for network-node use, CPU-16-RTO is the CAB-4 retrofit version, and N16x is the modular platform.
