Notifier HS-NCM-WMF-2 is a High-Speed Network Communications Module that connects a Notifier panel or network device to High-Speed NOTI•FIRE•NET (NFN) over twisted-pair wire on one port and multimode fiber on the other. It lets wire and fiber nodes communicate as one network.
The HS-NCM family serves the N16, NFS-320, NFS-640, NFS2-640, NFS-3030 and NFS2-3030 panels, NCD, NCA and NCA-2 displays and annunciators, and the DVC Digital Voice Command. Each module handles up to two node addresses, and when it is not connected to a panel it defaults to repeater mode, which can bridge segments where wire and fiber co-exist.
Specifications
| Media |
Twisted-pair wire and multimode fiber |
| Fiber type |
62.5/125 µm or 50/125 µm multimode |
| Max attenuation |
10 dB (62.5/125 µm), 6.5 dB (50/125 µm) |
| Wavelength |
1310 nm |
| Wire distance |
Up to 3,000 ft node to node |
| Wiring |
NFPA Class A or Class B |
| Node addresses |
Up to two per module |
Features
- Pluggable service connector passes the signal through if a node must be powered down
- Data is regenerated at each node
- Two network ports for simultaneous connection to the panel and a programming computer
- Software and database upload/download over High-Speed NFN
Installation notes
- Fiber must exit one board on TX and enter the next on RX; Port A of one node connects to Port B of the next
- Connects to HS-NCM-WMF-2, HS-NCM-WSF-2, HS-NCM-MFSF, HS-NCM-MF and HS-NCM-SF
- Refer to the High-Speed NFN manual (P/N 54013) and HS-NCM manual (P/N 54014) for network design
Related models
HS-NCM-W-2 is the wire-only version and HS-NCM-MF the multimode fiber-only version. It is compatible with the older HS-NCM-WMF with a different configuration.
