Notifier FSP-951T — white, low-profile intelligent photoelectric smoke detector with a built-in 135°F (57°C) fixed-temperature thermal sensor, for FlashScan systems only.
The FSP-951 Series plug-in detectors report their own address to the panel over the two-wire SLC, set with rotary decimal switches. Dual electronic thermistors add the 135°F fixed heat sensing on the T model. The detector plugs into a separate base, so photoelectric, ionization and thermal heads can be interchanged without rewiring.
Specifications
| Sensitivity |
UL: 0.5% to 4.0% per foot obscuration |
| Thermal |
135°F (57°C) fixed temperature |
| Protocol |
FlashScan only |
| Voltage range |
15 to 32 VDC peak |
| Current |
200 µA standby (max. average), 4.5 mA max with LED on |
| Operating temperature |
32°F to 100°F (0°C to 38°C) |
| Humidity |
10% to 93% non-condensing |
| Size |
2.0 in. high; diameter set by the base (6.1 in. on B300-6, 4 in. on B501) |
| Weight |
3.4 oz (95 g) |
Features
- Two LEDs with a 360° view, blinking when polled and steady in alarm
- Built-in functional test switch activated by an external magnet, plus remote test from the panel
- Removable cover and insect-resistant screen for field cleaning
- Optional relay, isolator and sounder bases
Installation notes
- Mount the base on an electrical back box at least 1.5 in. deep.
- End-of-line resistors are not required on the SLC; T-taps are allowed on Class B wiring only.
Related models
-
FSP-951 — photoelectric only.
-
FSP-951T-IV — ivory photo/thermal version.
-
FSP-951R — remote test capable version for DNR duct housings.
Documents
FAQ
Does the FSP-951T work on CLIP systems?
No. Notifier lists the FSP-951T as FlashScan only.
What does the "T" add?
A built-in 135°F (57°C) fixed-temperature thermal sensor, using dual electronic thermistors, alongside the photoelectric smoke sensor.
Is a base needed?
Yes. The detector plugs into a separate base, such as the B300-6 6 in. flanged base or the B501 4 in. base, or a relay, isolator or sounder base.
What temperature range is it rated for?
The FSP-951T Series operates from 32°F to 100°F (0°C to 38°C), lower than the 122°F limit of the photo-only FSP-951.
