The Notifier BB-200 is a combination power supply and battery enclosure for NFS2-3030 systems that need more standby battery capacity than the main cabinet holds. It is compatible with the AMPS-24 power supply and holds a power supply plus up to four BAT-12100 100 AH batteries, for a total of 200 AH.
Key Features
- Lockable door, hinged on the left, shipped assembled
- Holds a power supply and up to four BAT-12100 100 AH batteries (200 AH capacity)
- Mounts a minimum of 6 in (15.24 cm) below the fire alarm control panel
- Knockouts on the top and sides for conduit entry, plus a grounding wire
- Mounting holes take hardware up to 3/8 in
Specifications
-
Manufacturer: Notifier
-
Part Number: BB-200
-
Type: Power supply and battery backbox/enclosure
-
Battery Capacity: Up to four BAT-12100 100 AH batteries (200 AH)
-
Dimensions: 30 in W x 36 in H x 7.5 in D (76.20 x 91.44 x 19.05 cm), depth includes door
-
Loaded Weight: Over 300 lb when fully loaded; the wall may need extra support
-
Mounting: Wall mount, at least 6 in (15.24 cm) below the FACP
Compatibility
For Notifier NFS2-3030 systems when larger batteries are needed. Compatible with the AMPS-24 power supply. According to the NFS2-3030 datasheet, the AMPS-24 charges batteries from 7 to 200 AH, and batteries larger than 26 AH need a separate cabinet such as the BB-200.
