Notifier ACM-30 — AIO-bus annunciator control module for the INSPIRE N16 platform and the NCD.
The ACM-30 breaks with earlier NOTIFIER practice: nothing on its face is fixed in hardware. Every LED and touchpoint is mapped in VeriFire Tools, and in Independent mode one module can be built out as point indicators rather than paired alarm and trouble positions. It is also the module used for manual speaker and telephone circuit selection with a DVC.
- 62 LEDs, each programmable to one of eight colors, plus 32 capacitive touchpoints
- 62 points each; up to 80 annunciators and 4,960 points per N16 system
- Up to 10 units act as routers, each supporting 15 peripherals
- 18–30 VDC, 93 mA max; power must be power-limited and non-resettable
- Four wires: EIA-485 AIO bus plus 24 VDC; onboard selectable EOL resistors
- 32° to 120°F; UL S635, FM approved
N16 Series and NCD only — not a substitute for ACS-bus annunciators on NFS-series panels. Backbox or dress panel is ordered separately.
