| General: Status indication |
LED's |
| General: User interface |
TFT and navigation buttons on Normal and Command Display Modules |
| General: Alarm levels |
4 (Aux, Pre-alarm, Alarm and Alarm 2) |
| General: Event log |
20,000 events per module |
| General: RS485 support |
Yes (SenseNET+) |
| General: Connectivity |
USB Master - Type A (storage drive) USB Slave – Type B (remote connectivity) Ethernet – CAT 5, 5e or 6 cable (remote connectivity) |
| Electrical: Operating voltage |
24 VDC nominal (18.0V to 30.0V) |
| Electrical: Current consumption |
Detector Module (at 24 VDC): 218 mA – fan speed 1 330 mA – fan speed 6 (default speed) 762 mA – fan speed 16 |
| Electrical: SenseNet+ |
Twisted pair wire, 32 ohms, .44uf max |
| Detection principle |
Laser light scattering mass detection and par- ticle evaluation |
| Detection: Particle sensitivity |
0.003 to 10 microns |
| Detection: range Sensitivity Range |
[0,00914 – 7,62] %obs/ft [0,03 – 25%] %obs/m |
| Detection: Velocity Range |
0-4000 FPM |
| Sampling pipe: Length |
Up to 820 ft* (250 m) combined per detector module |
