| General: Status indication |
LED's |
| General: User interface |
TFT and navigation buttons on Normal and Command Display Modules |
| General: Alarm levels |
4 (Aux, Pre-alarm, Alarm and Alarm 2) |
| General: Event log |
20,000 events per module |
| General: RS485 support |
Yes (SenseNET and SenseNET+) |
| General: Connectivity |
USB Master - Type A (storage drive) USB Slave – Type B (remote connectivity) Ethernet – CAT 5, 5e or 6 cable (remote con- nectivity) |
| Electrical: Operating voltage |
24 VDC nominal (18.0vdc to 30.0vdc) |
| Electrical: Current consumption |
Command Display Module (at 24 VDC) 232 mA - Command Display Module |
| Electrical: SenseNet, SenseNet+ |
Twisted pair wire, 32 ohms, .44uf max |
| Input quantity |
2 per module |
| Input type and rating |
Supervised |
| Input: Termination |
15 KΩ 5% 1/4 W |
| Input: Programmable |
Yes |
| Output quantity |
3 per module |
