The Mircom MIX-M502MAPA Interface Module is an intelligent addressable interface designed to integrate conventional two wire smoke detectors into Mircom fire alarm systems.
This module monitors one full zone of conventional detectors and transmits alarm, normal, and fault conditions directly to the fire alarm control panel for reliable system supervision.
Designed for intelligent two wire systems, the MIX-M502MAPA features rotary address switches for easy configuration and installation. It provides dependable monitoring and communication, making it ideal for retrofit projects and system expansions where conventional detectors need to be integrated into addressable systems.
The Mircom MIX-M502MAPA mounts directly into a standard electrical box and includes a panel controlled LED indicator for quick status identification. This module is well suited for commercial, institutional, and industrial fire alarm applications requiring reliable detection monitoring.
Key Features
• Addressable interface module for conventional detectors
• Monitors one zone of two wire smoke detectors
• Transmits alarm, open, and normal conditions
• Rotary switches for easy addressing
• Panel controlled LED status indicator
• Compatible with intelligent Mircom systems
• Ideal for retrofit and expansion applications
• Compact design for easy installation
Specifications
• Operating Voltage: 15 to 32 VDC
• Maximum Alarm Current: 5.1 mA
• Average Operating Current: 400 µA
• IDC Supply Voltage: 24 VDC power limited
• Maximum IDC Wiring Resistance: 25 Ohms
• Temperature Range: 32°F to 120°F (0°C to 49°C)
• Humidity: 10% to 93% non condensing
• Dimensions: 4.5 in H x 4 in W x 1.25 in D
Applications
• Fire alarm system expansion
• Addressable system retrofits
• Commercial buildings
• Industrial facilities
• Schools and universities
• Healthcare facilities
• Office buildings
Manufacturer: Mircom
Model: MIX-M502MAPA
Type: Interface Module
System Type: Addressable Fire Alarm
The Mircom MIX-M502MAPA Interface Module provides a reliable and efficient solution for integrating conventional smoke detectors into intelligent Mircom fire alarm systems while maintaining full monitoring and control capabilities.
