Mircom FHS-400-RR — red wall-mount LED horn/strobe for indoor notification appliance circuits.
LED strobe optics draw far less than a xenon equivalent, which lets a designer hang more appliances on a NAC before adding a booster supply. Candela and tone are set from the back of the unit so they cannot be altered once it is mounted, yet the selected candela stays readable through the front window at inspection.
- Field-selectable candela: 15, 15/75, 30, 75, 110 and 185 cd
- Temporal, continuous, march time and 20 BPM tones, each at high or low volume
- 24 VDC regulated or 24 VFWR nominal; 16 to 33 V RMS operating range
- 30 mA at 15 cd and 180 mA at 185 cd (24 VDC, temporal, high volume)
- 84.9 dBA at 10 ft, temporal high volume, 24 VDC per UL 464
- 4-27/32" × 4-27/32" (123 × 123 mm); 12 to 22 AWG; 1 Hz flash rate
- UL 464, UL 1638, UL 1971, ULC-S525, ULC-S526
Indoor use only, 32° to 122°F. Wet or outdoor locations require the FHS-400-WP instead. Surface mounting needs a BB-400R back box, ordered separately.
