Mircom CM-RQE70A is a passive infrared (PIR) request-to-exit motion detector. It is small enough to mount on a door frame, and it replaces the CM-RQE70.
It has two Form C relay outputs, door monitoring and a tamper alarm, and inputs for a secondary activation device, card or keypad, door position switch and request-to-exit. Four factory default operating modes are selected with push buttons on the circuit board, and there are no DIP switches.
Features
- Compact size for door-frame mounting
- On-board programming buttons, no DIP switches
- 4 factory default operating modes that can be customized
- Selectable fail-safe or fail-secure operation
- 2 Form C contacts, momentary and latching relay modes
- Inputs for secondary activation device, card/keypad, door position switch and request-to-exit
Specifications
| Sensing |
Passive infrared (PIR), up to 10 ft |
| Input voltage |
12/24 VDC |
| Replaces |
CM-RQE70 |
| Dimensions (L x W x H) |
7.3 in x 2.5 in x 1.9 in |
| Color |
White |
| Certifications |
UL certified, RoHS |
