Mircom CM-30E is a green illuminated push-to-exit button with a single-gang stainless steel faceplate. It carries a single PUSH TO EXIT label.
CM-30 Series request-to-exit switches are designed to control electric locks, electromagnetic locks, electric strikes and low-energy door operators. They are also used for shunting, bypassing alarms and timed functions. The product data states that they meet NFPA code requirements and are ADA compliant. The CM-30EE adds double-break circuitry where an electronic time delay is needed.
Features
- Green illuminated 2 in square button
- Single PUSH TO EXIT label
- LED lamp with an estimated life of 10 years
- 12/24 VDC
- SPDT Form C contact rated 10 A at 30 VDC
- Momentary action
Specifications
| Button |
2 in square, green lens |
| Faceplate |
Single gang, stainless steel |
| Input voltage |
12/24 VDC |
| Contact |
SPDT Form C, 10 A at 30 VDC |
| Action |
Momentary |
| Dimensions (H x W x D) |
4.5 in x 2.8 in x 2 in |
