Macurco HS-C Horn Strobe Combo (Clear) - Works With Macurco Control Panels And 6-Series Detectors
The HS-C is the clear-lens combination horn/strobe in the Macurco notification series, used to give an audible and visual signal when a gas detection system goes into alarm. It works with Macurco control panels and Macurco 6-Series and 12-Series detectors, and can be flush or surface mounted on a standard 4 in. x 4 in. electrical box.
Key Features
- Combination horn and LED strobe with clear lens
- Strobe candela adjustable: 15, 30, 75 or 110 cd
- Two tone patterns: Continuous or Temporal 4, each high/low volume
- Strobe flash rate: 1 flash per second, 20 ms pulse
- Low current draw
- Flush or surface mount on a standard 4x4 electrical box
- Works with Macurco control panels and 6 & 12 Series detectors
Specifications
| Nominal voltage |
Regulated 24 VDC |
| Operating voltage |
16 to 33 VDC |
| Sound output (reverberant, UL 464) |
Continuous 91.4 / 86.6 dBA (high/low); Temporal 4 87.5 / 82.2 dBA |
| Operating environment |
32 to 120 F (0 to 49 C), 10-93% RH |
| Size |
5-1/2 x 4-3/4 x 2 in. (14 x 12 x 5 cm) |
| Lens color |
Clear |
Compatible With
- Macurco DVP-120 / DVP-120M control panels
- Macurco 6-Series and 12-Series detectors
