Kidde WG4WF-HVMC is a Genesis WG4 Series outdoor-rated horn strobe with a white housing, FIRE marking and a selectable standard candela strobe. It is rated for indoor or outdoor use on walls or ceilings, with a rated operating temperature range of -40°F to 151°F, and is fully compatible with Genesis synchronization protocols.
Light and sound output settings are field selectable, and the strobe setting stays visible through a small window after the cover is closed. For outdoor or wet surface mounting, use the 449 or 74347U outdoor-rated box; in dry locations a standard 4 in. square by 1-1/2 in. deep box can be used.
Specifications
| Type |
Horn strobe, outdoor and indoor rated |
| Strobe |
Selectable standard candela output |
| Housing |
White, FIRE marking |
| Mounting |
Wall or ceiling |
| Horn output |
Up to 97 dBA (UL 464), 104 dBA (ULC-S525) |
| Operating temperature |
-40°F to 151°F (-40°C to 66°C) |
| Wiring |
Room-side, 18 to 12 AWG (0.75 to 2.5 mm²) |
| Ship weight |
1.5 lb (0.68 kg) |
Installation notes
- Outdoor or wet locations: mount to a 449 or 74347U surface box
- Optional WG4WTS white surface skirt and WG4GSKT full body gasket for smooth surfaces
Related models
- WG4WF-HVMHC: white, FIRE, high candela
- WG4WN-HVMC: white, no marking, standard candela
- WG4RF-HVMC: red, FIRE, standard candela
- WG4WF-H: white, FIRE, horn only
Documents
FAQ
What back box is needed outdoors?
For surface mounting in outdoor or wet locations, mount to a 449 or 74347U electrical box. In dry conditions a standard 4 in. square by 1-1/2 in. deep box can be used.
What is the difference between -HVMC and -HVMHC?
The -HVMC models have a selectable standard candela strobe; the -HVMHC models have a selectable high candela strobe.
How loud is the horn?
Genesis WG4 horn output reaches up to 97 dBA per UL 464 (104 dBA per ULC-S525), depending on voltage and setting.
What temperatures is it rated for?
-40°F to 151°F (-40°C to 66°C), indoors or outdoors.
