Kidde KC2-RB4 — relay mounting base for Optica KC2 series conventional two-wire detectors, with tabs for a 4 in. square box.
A conventional two-wire initiating circuit carries no address, so any local action at the device — damper, door holder, fan shutdown, ancillary annunciation — has to come from a relay in the base. The KC2-RB4 provides it: the contacts change state automatically when the detector head goes into alarm. Wiring terminals stay accessible from the room side once the base is screwed to the box.
- Accepts KC2 series heads, including KC2-OS-CD optical smoke and KC2-H-CD heat
- Trim skirt included to hide the square-box mounting tabs
- Base 4.4 in. (11.18 cm) diameter, 0.75 in. (1.9 cm) off the box
- Also mounts to single-gang, 3-1/2 in. and 4 in. octagon and BESA boxes
The GSA-LED remote alarm indicator is listed for the KC2-SB and KC2-SB4 standard bases only, so do not substitute a relay base where a remote indicator is required. KC2 bases do not take Kidde KI series heads.
