Kidde K-270-SPO is a single-action, break-glass manual fire alarm station from the K-270 Series of non-coded stations. It has a single-pole, open-circuit (normally open) switch and screw terminals for field connection. It is fire alarm red with aluminum strips and marked "Pull in Case of Fire" on the pull handle.
Specifications
| Action |
Single action, pull lever, break glass |
| Contacts |
Single pole, open circuit (N.O.) |
| Field connections |
Screw terminals |
| Pull force |
Under 5 lb (ADA) |
| Construction |
Solid die-cast metal |
| Finish |
Fire alarm red with aluminum strips |
| Mounting |
Flush or surface |
Installation notes
- Flush mount with a 4 in. standard North American square box and single-gang plaster cover
- Surface mount with a cast box, steel box, or weatherproof housing
- The station does not operate without electrical power in the panel circuit
- Related models: K-270-DPO and K-270A-DPO (double pole), K-270P series (pre-signal)
