Kidde K-270-DOC — K-270 Series non-coded, single-action break glass fire alarm station in die-cast metal, with screw terminals for field connection.
The K-270 Series is designed for economical installation in conventional fire alarm systems. A single pull of the lever operates the station, and the pull force is less than 5 lb to comply with ADA. The series is built with normally open, normally closed or combination N.O./N.C. contacts depending on the model. All models are fire alarm red with aluminum strips and are marked "Pull in Case of Fire" on the pull handle.
Specifications
| Model |
K-270-DOC |
| Series |
K-270 non-coded fire alarm stations |
| Operation |
Single action, pull lever, break glass |
| Field connections |
Screw terminals |
| Construction |
Die-cast metal, red with aluminum strips |
| Pull force |
Less than 5 lb (ADA) |
| Certifications |
UL S2318; CSFM 7150-1657:0111 |
Installation notes
- Flush mounting: use a 4 in. standard North American square box with a single-gang plaster cover
- Surface mounting: use a cast box, steel box, or a housing for a weatherproof enclosure
- Field wiring connects to screw terminals
Related models
- K-270 Series stations with single-pole or double-pole open circuit contacts
- K-270A Series with 6 in. wire leads
- K-270P Series pre-signal stations
Documents
FAQ
Is the K-270-DOC single or dual action?
It is a single-action station: one pull of the lever initiates the alarm, with a pull force under 5 lb.
How is it mounted?
For flush mounting, use a 4 in. standard square box with a single-gang plaster cover. For surface mounting, use a cast box, steel box, or housing for a weatherproof enclosure.
Is this a coded station?
No. The K-270 Series are non-coded fire alarm stations for conventional systems.
