Kidde GCI is a graphic annunciator driver master. It provides outputs for 32 LEDs and a connection to common control switches and LEDs for R-Series annunciators.
The driver is an interface card between an intelligent control panel and an LED-based graphic annunciator display panel (sold separately). It communicates with the control panel over an RS-485 data riser that can be set up for Class A or Class B. The card includes status LEDs and an internal buzzer, and mounts on snap track attached to a plastic rail that spans two EIA panels.
Features
- Drives up to 32 LEDs on the E-FSA250 graphic display and 16 on the E-FSA64
- Five dedicated switch inputs for common controls
- Sixteen programmable switch inputs
- Eleven dedicated LED outputs for power, common controls, system status and enable indicators
- Built-in status LEDs and internal buzzer
- Class A or Class B RS-485 communication
Specifications
| Product type |
Annunciator module |
| Input voltage |
24V DC |
| Color |
White |
| Operating temperature |
32 to 120 °F (0 to 48.9 °C) |
| Mounting |
Snap track on plastic rail, two EIA panels |
