Kidde EWGVWF is a white outdoor strobe with FIRE marking from the Genesis LED WG series. The series carries an IP66/NEMA 4X rating for wet and harsh environments.
The strobe has a clear lens and settings that can be configured in the field. Candela settings stay visible through a sealed viewport after installation, and the timing meets UL 1971 synchronization standards.
Features
- IP66/NEMA 4X rated for outdoor and harsh environments
- Operating temperature -40 to 151 °F (-40 to 66 °C)
- Clear lens with FIRE marking, white housing
- Field-configurable light output settings
- Sealed viewport shows the candela setting after installation
- Series supports wall or ceiling mounting, including recessed (in-the-pour or block) electrical boxes
- Room-side wiring
- Precision timing to UL 1971 synchronization standards
Specifications
| Type |
Outdoor strobe |
| Protection rating |
IP66 / NEMA 4X |
| Temperature range |
-40 to 151 °F (-40 to 66 °C) |
| Color |
White |
| Marking |
FIRE |
| Lens |
Clear |
