Kidde EGC-HDVMH Horn Strobe, Ceiling Mount, 95-177 CD, 24VDC, White
Kidde Genesis ceiling horn-strobe with a white housing and no text marking. It is the high-candela model: strobe output is selectable at 95, 115, 150 or 177 cd, and the temporal horn has high/low dB settings. It mounts to a 4 in. square electrical box for indoor ceiling or wall use on 24 V notification circuits.
Key Features
- Field-selectable 95/115/150/177 cd strobe; setting stays visible after installation
- Temporal-tone horn with high or low dB output
- Low-profile round housing, no visible mounting screws
- Fits a standard 4 in. square box; #18 to #12 AWG terminals
- Indoor ceiling or wall applications
Specifications
| Strobe output |
Selectable 95, 115, 150 or 177 cd |
| Housing color |
White |
| Marking |
None |
Compatible With
- EG1M-RM Genesis Signal Master
- GSA-CC1S / GSA-MCC1S synchronization modules
