Kidde EG4SRF is a red wall speaker marked FIRE from the Genesis LED EG4S Series, supplied with a room-side wiring plate. Its low-profile housing keeps the speaker compact.
The speaker has selectable wattage taps and a field-selectable switch for 25 V or 70 V operation. A DC blocking capacitor allows electrical supervision of the audio distribution circuit.
Features
- Selectable wattage taps
- 25 V and 70 V operation selectable by switch
- Low frequency (520 Hz) capable, for sleeping area requirements
- High-fidelity output with good speech intelligibility (STI)
- DC blocking capacitor for audio circuit supervision
- Room-side wiring plate included
- FIRE marking, red housing
Specifications
| Type |
Wall speaker |
| Mounting |
Wall |
| Color |
Red |
| Marking |
FIRE |
| Height |
5.8 in |
| Width |
5 in |
| Depth |
1.6 in |
