Kidde EG1VWF — Genesis LED EG1 Series wall strobe, white housing with FIRE lettering and field-selectable candela.
The EG1 Series is the compact Genesis LED line: single-gang appliances roughly an inch deep, with a quick-swap cover that changes the lettering without changing the device. High-efficiency optics focus the light pattern for a far lower current draw than a xenon flashtube, and EG1 strobes may be mixed with xenon devices on one circuit.
- Field-selectable 15, 30 or 75 cd, set by a slide switch visible through a window in the cover
- 24 mA on 16 to 33 VDC and 32 mA on 16 to 33 VFWR, at any candela setting
- Flash rate approximately 1 per second; UL 1971 certified for indoor public-mode wall use
- Synchronisation allows 20 Ω maximum between any two devices
- 3 × 4-5/8 × 1-1/8 in.; fits 1-gang, 2-gang, 4 in. octagon and square boxes at least 1-1/2 in. deep
EG1VWN is the same strobe without lettering and EG1VRF the red FIRE version. EG1AWF is horn-only and EG1AVWF the horn-strobe, both adding an audible element this part lacks. A box over three inches wide needs an EG1TW or EG1TR trim ring.
