Honeywell L-VHP15A/EN is a 15 W voice alarm horn loudspeaker for outdoor, dry or wet locations. It has a wide frequency response, low distortion and a high sound pressure level, and it is certified to EN 54-24.
Power taps of 15 W, 10 W and 5 W are available on a 100 V or 70 V line. The housing is rated IP66.
Features
- Rated power of 15 W with 15/10/5 W taps
- Sound pressure level of 117 dB at 15 W and 105 dB at 1 W (1 m, 100 Hz to 10 kHz)
- Frequency response of 300 Hz to 16 kHz (-10 dB)
- For 100 V or 70 V input
- EN 54-24 certified and IP66 rated
- Grey housing (RAL 7035)
Specifications
| Rated power |
15 W |
| Rated input voltage |
100 V / 70 V |
| Rated impedance |
667 Ω / 1000 Ω / 2000 Ω |
| Dimensions |
8.4 in. diameter x 10.4 in. (213 x 265 mm) |
| Weight |
4.5 lb (2.05 kg) |
| Relative humidity |
Up to 95% |
