Honeywell CCM2-AV-HON — 4G LTE dual-SIM cellular communication module that plugs into the Connected Life Safety Services gateway, HON-CGW-MBB.
CLSS is the Honeywell cloud platform for fire systems, and the CLSS Gateway bridges a Honeywell fire alarm control panel, or a network of them, to it. This module gives that gateway a cellular path in place of wired or Wi-Fi access.
- Factory-mounted dual SIMs for both major US carriers, Verizon primary at power-up with automatic fallback
- The default primary network can be swapped in the CLSS Mobile App or Site Manager
- Sends alarm, supervision, trouble and test messages to the central station and the CLSS Cloud
- LTE Cat 1 on bands 2, 4, 5, 7, 12, 13, 14, 25, 26
- Plugs onto the 40-pin gateway expansion slot and is powered by it; firmware 4.6.0.56 or later
- ETL listed to UL 864 through the HON-CGW-MBB; NFPA 72 Chapter 26
For fixed installations only. The primary antenna is included; the CCM2-ANTKIT-EXT2 diversity antenna and the CCM2-ANTKIT-OUT25 and OUT50 outdoor kits are separate. CCM-ATT-HON and CCM-VZ-HON are the earlier single-carrier modules.
