Gentex GSSR (904-1507-002) is a universal-mount speaker strobe with a red faceplate and FIRE lettering. It combines a 25 or 70.7 VRMS speaker with a selectable candela LED strobe and replaces the SSPK24CLPR.
The speaker mounts on a ceiling or a wall, and its power tap is field selected. The strobe holds a constant 1 Hz flash rate regardless of input voltage and can be synchronized with a Gentex AVSM control module.
Features
- Universal mount for ceiling or wall applications
- Selectable candela LED strobe; candela settings are tamperproof
- Strobe nominal voltage of 24 V DC
- Speaker voltage of 25 or 70.7 VRMS, field selectable
- Power taps of 1/8, 1/4, 1/2, 1, 2 and 4 W
- Frequency range of 400 to 4000 Hz
- Screw terminals with separate in/out wiring for 12 to 18 AWG
Specifications
| Product type |
Speaker strobe |
| Faceplate |
Red, FIRE text |
| Strobe voltage |
24 V DC |
| Speaker voltage |
25 or 70.7 VRMS |
| Frequency range |
400 to 4000 Hz |
| Wire size |
12 to 18 AWG |
| Replaces |
SSPK24CLPR |
