Gentex GHSLF110R is a red, low-profile, wall-mount low frequency horn strobe for fire alarm use, with a clear lens. The horn produces a 520 Hz square wave in a temporal 3 pattern, and a jumper selects a normal or loud output.
A temporal 4 pattern is available when the unit is used with the Gentex GTSM synchronization control module. The 4 inch metal mounting plate has the Super-Slide feature for supervision testing.
Features
- 520 Hz square wave, temporal 3 tone
- Jumper selection for normal or loud decibel output
- Fixed candela strobe (the GHSLF series offers 15, 110 and 177 cd)
- Super-Slide bracket and a locking mechanism that hides the mounting screws
- Checkmate instant voltage verification
- Compatible with the Gentex GTSM synchronization control module
- Certified to ANSI/UL 1971, ANSI/UL 464, CAN/ULC S525 and CAN/ULC S526; three-year warranty
Specifications
| Product Type |
Low frequency horn strobe |
| Voltage |
24 V DC nominal |
| Color |
Red |
| Lens |
Clear |
| Mounting |
Wall |
| Height |
6.5" (16.5 cm) |
| Width |
5.5" (14.0 cm) |
| Depth |
2" (5.0 cm) |
