Gentex GECR24PWR (904-1333-002) is a wall-mount horn/strobe with a red lens, a red faceplate and no lettering on the cover. It comes from the Commander3 colored lens series of 24 V DC signals used for warning and emergency notification.
Tones are set with switches in the field: continuous or temporal 3 in 2400 Hz, mechanical, chime, or a whoop tone. The included 4 in. mounting plate has the Super-Slide feature for supervision testing, and a locking mechanism holds the signal on the bracket with no visible screws.
Features
- Nominal voltage of 24 V DC
- Tamperproof, field-selectable strobe candela (series options are 15, 30, 60, 75 and 110 cd)
- Switch selection of high or low dBA output
- Tone switch for chime, whoop, mechanical or 2400 Hz
- Switch for continuous or temporal 3 (not available on the whoop tone)
- Checkmate feature for instant voltage verification
- Strobe and/or horn can be synchronized with a Gentex AVSM control module
- Input terminals accept 12 to 18 AWG wire
Specifications
| Product type |
Horn/strobe |
| Alarm type |
Audible and visual |
| Voltage |
24 V DC |
| Sound emission |
100 dB |
| Lens color |
Red |
| Mounting |
Wall |
| Height |
5 in. |
| Width |
4.5 in. |
| Depth |
2.5 in. |
| Series certifications |
ANSI/UL 1638, ANSI/UL 464, CAN/ULC S525 and/or S526 |
