This bulk pack contains ten Gamewell-FCI MS-7AF double-action addressable pull stations from the Velociti® Series. The MS-7AF-BP suits multi-station projects. Each station installs on the signaling line circuit of a Gamewell-FCI analog addressable control panel, and pulling it registers the station's address at the panel.
Key Features
- Double-action operation helps reduce accidental activations
- LED on the door flashes green in normal condition and lights steady red when activated (only the red LED works on panels not in Velociti mode)
- Velociti protocol responds up to five times faster than earlier designs
- Meets the ADA 5 lb maximum pull force. Operating instructions and Braille are engraved in the handle
- Key lock/reset keyed alike with Gamewell-FCI control panels
- Screw terminals; surface or semi-flush mounting
Specifications
-
Manufacturer: Gamewell-FCI
-
Part Number: MS-7AF-BP (10 x MS-7AF)
-
Series: Velociti® addressable
-
Material: Lexan®
-
Dimensions: 5-5/8 in H x 4-1/4 in W x 1-1/4 in D (14 x 10.1 x 3.2 cm)
-
Alarm Current: 0.0030 A (0.007 A with LED)
-
Supervisory Current: 0.00030 A
-
Operating Environment: 32°F to 120°F; 10% to 93% RH, non-condensing
-
Mounting: Standard double-gang or 4 in square electrical box; optional BG12TR trim ring for semi-flush
-
Listings (MS-7 Series): UL S2465; FM 3023594
Compatibility
For use only with Gamewell-FCI analog addressable fire alarm control panels.
