Gamewell-FCI LCD-SLP — Liquid Crystal Display, Smart Loop Panel: a 4.3 in. color touchscreen annunciator display for S3 Series and E3 Series® systems.
The LCD-SLP gives the operator an intuitive interface to the panel. Its 4.3 in. (10.92 cm) color touchscreen shows system status, event details and service modes, backed by six LED indicators — AC power (green), fire alarm (red), hazard (blue), supervisory (yellow), trouble (yellow) and silenced (yellow) — where the hazard LED indicates gas, carbon monoxide or other toxic gases. Five fully programmable front-panel switch/LED combinations give direct access to tasks such as device bypass, lamp test and enable/disable of groups or devices, alongside physical Menu, System Reset and Drift Walk Test switches. Both the E3 Series (ILI-MB-E3 / ILI95-MB-E3) and the S3 Series (SLP) support up to 15 LCD-SLP displays over the RS-485 serial interface, so the same display serves as the panel front end or as a remote annunciator elsewhere in the building.
Specifications
| Type |
LCD touchscreen annunciator display |
| Display |
4.3 in. (10.92 cm) color touchscreen — system status, event details, service modes |
| LED indicators |
AC power (green), fire alarm (red), hazard (blue), supervisory (yellow), trouble (yellow), silenced (yellow) |
| Programmable controls |
Five fully programmable switch/LED combinations (device bypass, lamp test, enable/disable groups or devices) |
| Physical switches |
Menu, system reset, drift walk test, plus the five programmable switches |
| Quantity per panel |
Up to 15 LCD-SLP displays on E3 Series (ILI-MB-E3 / ILI95-MB-E3) or S3 Series (SLP), via RS-485 |
| Operating voltage |
24 VDC FWR |
| Operating current |
0.030 A |
| Alarm current |
0.065 A |
| Operating temperature |
32°F to 120°F (0°C to 49°C) |
| Relative humidity |
0 to 93% non-condensing at 90°F (32°C) |
| Standard |
ANSI/UL 864 9th Edition; UL Listed and FM approved for pre-action/deluge and agent releasing |
| Listings |
UL S1869; FM approved; MEA FDNY COA #6162; CSFM 7165-1703:0176; City of Chicago Class 1; reference certificate of compliance VMA 45894-02C |
Installation notes
-
Three mounting options: locally in E3 Series and S3 Series panels, remotely in the E3 Series A2 cabinet, or in the LCD flush enclosure.
-
Remote enclosure ordered separately: remote mounting uses E3BB-BA2 (black) or E3BB-RA2 (red) remote enclosures with inner door and one LCD slot, or E3BB-FLUSH-LCD for flush mounting — the display unit itself is the LCD-SLP part number.
-
Cabinet compatibility: S3 Series SLP-BB and S3BB-BB/S3BB-RB enclosures; E3 Series AA, A2, A flush, B-Slim, B, C and D cabinets; and 600-RETROFIT, 7200-B-RETROFIT and 7200-C-RETROFIT retrofit cabinets. See the E3 Series Cabinets Data Sheet, P/N 9020-0649.
-
Display count: up to 15 displays per panel on the RS-485 serial interface — plan annunciator locations against that limit.
-
Hazard LED: the blue hazard LED is the indication for gas, carbon monoxide or other toxic gases, which matters where MCS-COF3 fire/CO detectors are on the loop.
Related models
-
E3BB-BA2 / E3BB-RA2 — remote enclosure with inner door, one LCD slot, black or red
-
E3BB-FLUSH-LCD — remote flush mounting enclosure, black, LCD slot
-
ILI-MB-E3 / SLP — the E3 Series main board and S3 Series Smart Loop Panel this display serves
Specifications taken from the Gamewell-FCI data sheet "LCD-SLP LCD Touchscreen Annunciator Display," document 9021-60782 Rev. F (09/17). Manufacturer specifications are subject to change without notice.
