Gamewell-FCI GWF-7075 is an addressable fire alarm control panel with one signaling line circuit (SLC) that supports up to 75 detectors and 75 modules using the System Sensor Velociti protocol. It also has built-in support for SWIFT wireless fire alarm devices, with up to four SWIFT gateways of up to 49 wireless devices each.
Two configurable notification appliance circuits deliver up to 2.5 A of output, and a built-in dual phone line digital alarm communicator, IP communications and an optional cellular module report events to the central station by point or by zone. The panel is programmed from the front panel or through a built-in USB port, and JumpStart Auto Programming speeds setup. It can be surface or flush mounted.
Specifications
| SLC capacity |
75 detectors and 75 modules, Velociti protocol |
| Wireless |
Up to 4 SWIFT gateways, up to 49 devices each |
| NACs |
2 configurable, 2.5 A maximum output |
| Display |
Four-line LCD, 40 characters per line |
| Communicator |
Built-in dual-line DACT and IP; optional cellular |
| Wiring |
Class B (Style 4) and Class A (Style 6 or 7) for SLC and SBUS |
| Programming |
Front panel, USB, JumpStart Auto Programming, HFSS software |
| Cabinet |
Red (GWF-7075) or black (GWF-7075B); surface or flush mount |
Features
- Detector sensitivity, day/night thresholds, drift compensation, pre-trouble maintenance and calibration trouble alerts
- Built-in strobe synchronization for compatible System Sensor, Gentex, Wheelock, Faraday and AMSECO appliances
- Daylight Saving Time date setting and field-upgradable firmware
- SBUS accessories: RA-1000 remote annunciator, 5880 LED I/O module, 5824 serial/parallel printer module, GFPS-6S remote power supply
- 5220 direct connect module for a city box or polarity reversal connection
Related models
- GWF-7075B: same panel in a black cabinet
- BB-17F: remote battery box for up to two 18 Ah batteries
Documents
FAQ
How many devices does the GWF-7075 support?
Its SLC supports up to 75 detectors and 75 modules in Velociti mode, plus up to four SWIFT wireless gateways with up to 49 wireless devices each.
Does it have a built-in communicator?
Yes. It has a built-in dual phone line DACT and IP communications, with an optional cellular communication module.
What annunciators and modules can I add?
On the SBUS it supports the RA-1000 remote annunciator, the 5880 LED I/O module (up to eight), the 5824 printer interface and the GFPS-6S intelligent remote power supply.
Which strobes can it synchronize?
Built-in synchronization works with some System Sensor, Gentex, Wheelock, Faraday and AMSECO appliances; Gamewell-FCI lists the compatible models in its Compatibility Addendum, P/N 9000-0427-L8.
