Gamewell-FCI E3BB-BD/INCC is the black D-size Command Center enclosure, the tallest cabinet in the E3 Series range. It holds the most sub-assemblies and is used for large voice evacuation command centers. Inner doors E3ID2-D and E3ID3-D and the E3-INCC-D-PLATE mounting plate are specified for this size.
Specifications
| Cabinet size |
D |
| Color |
Black |
| Dimensions |
19 3/8 in. W x 41 in. H x 4 1/2 in. D (49 x 104 x 11 cm) |
| Mounting plate |
E3-INCC-D-PLATE |
| Backbox |
16-gauge steel |
E3-INCC-D plate capacity
- PM-9 or PM-9G power supply: 1
- ILI-MB-E3 or ILI95-MB-E3 loop interface: 1, plus up to 4 additional
- DACT-E3: 1; RPT-E3: 1; INI-VG Series: 1
- Optional AM-50 or FPT-GATE-3 extender plate: 1
- E3BB-RD/INCC is the red version
E3 Series cabinet features
- 16-gauge steel backbox with mounting patterns for sub-assembly plates
- Backbox knockouts positioned for conduit access
- Removable outer and inner doors with an inner door bonding strap
- Keylock with quarter-turn latch; furnished ground studs on backbox and door
- Cabinets are UL 864 and UL 2572 certified and IBC seismic certified
