Fire-Lite SLC-3LS — loop expander card that adds one 318-point signaling line circuit to an ES-1000X Series addressable control panel.
An ES-1000X ships with one SLC loop card installed. When a building outgrows it, an SLC-3LS mounts on standoffs inside the panel and brings up a further independent loop, carrying the system toward its full 954-point capacity without replacing the panel. The card has its own supervised terminal block.
- Adds 318 addressable device addresses on one loop, 159 detectors and 159 modules
- Maximum of two cards per panel, giving three SLC loops and 954 points in total
- Loops wire as Class B, Class A or Class X (DCLB, DCLA or DCLC in Canada)
- All SLC connections supervised, power limited
- Three switches: ground fault disable, a 16-position loop address switch on which 0 is not valid, and RS-485 termination
- LiteSpeed polling; SLC runs to 10,000 ft. on twisted unshielded wire
It expands loop capacity rather than annunciation, so it is not an alternative to ANN-Bus modules such as ANN-80, and it is distinct from the IPOTS-COM communicator card above it in the same stack.
