Fire-Lite MS-10UD-7E — ten zone conventional fire alarm control panel with a built in digital alarm communicator, supplied for 240 VAC 50 Hz mains.
The trailing E is the export mains build, not a feature grade: Fire-Lite lists it at 240 VAC 50 Hz where the MS-10UD-7 is 120 VAC 60 Hz. The integral DACT reports alarms, troubles and AC loss to a central station over telephone lines.
- AC input 240 VAC, 50 Hz, 2.20 amps with the FLPS-7 power supply
- Ten programmable Style B initiating device circuits, 4.7 kΩ end of line
- Four Style Y notification appliance circuits, 3.0 amps maximum per circuit
- 7.0 amps maximum total alarm current per panel
- Three programmable Form C relays, 2 amps at 30 VDC resistive
- 80 character backlit LCD, 256 event history, programmed from the keypad
- Charger rated to 26 Ah; two 18 Ah batteries fit in the cabinet
The MS-10UD-3E is the same export panel with the smaller FLPS-3 supply and 3.0 amps total alarm current; MS-10UD-7 is the 120 VAC version, MS-10UD-7C the ULC one. The DP-51050 dress panel and TR-CE trim ring are options; batteries above 18 Ah need a BB-26 or BB-55F box.
