Edwards GCARF Ceiling Horn, Red, Fire Marking
GP10 Room Side Wiring Plate Required, Ordered Separately.
Key Features
- High Performance LED Strobe Technology
- More devices per circuit
- Ability to use lower gauge wire
- Longer wire runs
- Fewer booster power supplies
- High efficiency optics
- Selectable 15, 30, 75, or 115 cd light output
- LED devices may be mixed with legacy Xenon strobes
- Efficient Audible Output
- Selectable high or low dB horn output
Specifications
| Operating voltage |
16 to 33 VDC, 16 to 33 VFWR |
| Horn signal type |
Constant or TC3 temporal |
| Light output |
15, 30, 75, or 115 candela |
| Strobe flash rate |
1 fps (flash per second) approx. |
| Synchronization Sources |
Edwards CC Series Signal Modules, Booster and Auxiliary Power Supplies, Intelligent and Conventional Control Panels |
| Wire size |
12 to 18 AWG (0.75 to 2.50 mm2) |
