Edwards G4SRN Speaker, Red, Wall Mount, No Marking
Genesis LED G4S Series speakers and speaker-strobes combine high performance output with a sleek low profile design and energy-efficient technology that makes them less expensive to install and operate. High performance LEDs require fewer power supplies, backup power, and batteries. These new appliances are designed with energy-efficiency, and life safety in mind. Speakers feature selectable wattage taps, while speakerstrobes allow for both wattage and light output levels to be configured in the field. Both settings remain clearly visible
Key Features
- High Fidelity performance with excellent STI
- Increased sound fidelity and audio intelligibility with an STI rating of.81 (More than.76 is excellent)
- Low Frequency (520Hz) capable
- Low frequency output meets NFPA standards for newly constructed commercial sleeping areas
- High Performance LED Strobe Technology
- More devices per circuit
- Ability to use lower gauge wire
- Longer wire runs
- Fewer booster power supplies
- High efficiency optics
Specifications
| Contact us Phone: Email |
edwards.fire@kgsolutions.com |
| Website |
edwardsfiresafety.com |
| Strobe operating voltage |
16 to 33 VDC, 16 to 33 VFWR |
| Speaker operating voltage |
25VRMS of 70VRMS (selectable) |
| Speaker frequency response |
400Hz-4,000Hz |
| (UL rated) Speaker frequency response 800-655-4497 (Option 4) (nominal) |
100Hz-11,000Hz |
| Light output |
15, 30, 75, or 110 candela |
| Strobe flash rate |
1 fps (flash per second) approx. 20 Ω max. between any two devices. To determine allowed wire resistance, refer to |
| Synchronization |
these specifications, and the specifications for the synchronized signal source. Edwards CC Series Signal Modules, |
| Synchronization Sources |
Booster and Auxiliary Power Supplies, Intelligent and Conventional Control Panels |
| Wire size |
12 to 18 AWG (0.75 to 2.50 mm2) |
