Edwards G1VRA-CVR Compact Wall Cover that is red and has an alert marketing visual
It is a replacement cover for the G1 Strobe ALERT.
Key Features
- High Performance LED Strobe Technology
- Ultra low device current consumption
- High efficiency optics
- Selectable 15, 30, or 75 cd light output
- LED devices may be mixed with legacy Xenon strobes
- Efficient Audible Output
- Selectable high or low dB horn output
- Selectable temporal or steady horn output
- Improved audio frequency range for better wall penetration
- Low-profile Design
Specifications
| Operating voltage |
16 to 33 VDC, 16 to 33 VFWR |
| Horn signal type |
Constant or T3 temporal |
| Light output |
15, 30, or 75 candela |
| Strobe flash rate |
1 fps (flash per second) approx. 20 Ω max. between any two devices. |
| Synchronization |
(To determine allowed wire resistance, refer to these specifications, and the specifications for the synchronized signal source.) |
| Synchronization sources |
EDWARDS CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels |
| Wire size |
12 to 18 AWG (0.75 to 2.50 mm2) |
