FW-CGS is the Edwards FireWorks OneView software license without command and control. FireWorks OneView displays fire panel events on a map or floor plan for first responders. The FW-CGS license gives the graphical view only; the FW-CGSUL license adds command and control such as panel and device silence and reset.
Specifications
| Product |
FireWorks OneView software license |
| Command and control |
Not included (see FW-CGSUL) |
| System |
FireWorks OneView graphical annunciator (FW-GA) |
Compatibility and installation notes
- A FireWorks OneView system needs at least one software license, either FW-CGS or FW-CGSUL.
- The OneView hardware is ordered separately, and both hardware parts are required: FW-GA-CABB enclosure with door and Lexan panel, and FW-GA-PC all-in-one computer and monitor.
- Edwards lists the OneView system to UL 864 10th Edition and as UL 2572 Recognized; the hardware is a semi-flush, wall-mounted enclosure.
Related models
-
FW-CGSUL: OneView software license with command and control.
Documents
Specifications from Edwards data sheet E85006-0073, FireWorks OneView Graphical Annunciator, Issue 1.2. Manufacturer specifications are subject to change.
