Edwards 6536A-G5 — CFA Series horn/strobe with an amber xenon lens, rated for 24 V AC or 24 V DC.
The 6536 is the audible and visual unit used in Edwards Call For Assistance stations, mounted above a door so staff can see and hear a call raised from a rest room or hotel room. It is certified to UL 1638, covering private mode and general utility visual signaling, rather than to UL 1971 for public mode fire notification.
- Amber lens rated 40 candela; xenon strobe, neutral white housing
- Operates on 24 V AC at 50/60 Hz or on 24 V DC
- Current 0.175 A at 24 V AC, 0.125 A at 24 V DC
- Sound output 92 dB at 1 m, 82 dB at 10 ft
- Fits a single gang 2" (51 mm) × 4" (102 mm) box
- Faceplate 4-1/2" × 4-9/16" (114 × 116 mm), projecting 13/16" (20 mm)
- UL 1638 certified
Lens colour changes the catalog number and the candela rating together: 6536-G5 clear is 50 cd, 6536R-G5 red 25 cd, 6536G-G5 green 29 cd and 6536B-G5 blue 17 cd. Edwards does not sell the coloured lenses as replacement parts, so order the amber unit outright. The 6538A-G5 and 7005A-G5 kits bundle this same horn/strobe with a transformer and a switch.
