Edwards 4-CAB24DR EST4 Door Assembly, Red Outer Door and Black Inner Door, 24 User Interface Spaces, Mounts to 3-CAB14B Wallbox

Edwards 4-CAB24DR — EST4 door assembly with a red outer door and a black inner door, 24 user interface spaces, for the 3-CAB14B wallbox.

The 4-CAB24DR is the front of an EST4 lobby enclosure or large annunciator. Edwards orders and ships EST4 backboxes, doors and chassis separately, so this carton holds the doors only: no wallbox, chassis, display or modules. The door can be hinged on the left or the right.

• 24 spaces, eight wide by three high, for control-display modules; an LCD takes two
• Mounts to a 3-CAB14B (surface or semi-flush) or a 4-24ANNMT wallbox (surface only)
• With a 3-CAB14B: room for two 17 Ah batteries and two chassis, 14 local rail module spaces
• 14-gauge rolled steel, red baked enamel finish
• Shipping weight: 51.0 lb

Not the 4-CAB24D (metallic bronze) or the 4-CAB24DRL, which is also red but fits the larger 3-CAB21B. The 4-CAB24DR-E is the EN54 version. Add a 4-TAMP if the cabinet needs a door tamper switch.

Documents

• EST4 Cabinets and Chassis E85014-0004 — Data Sheet (PDF)

FAQ

Is the wallbox included?
No. The 4-CAB24DR is the door assembly; it mounts on a 3-CAB14B backbox (surface or semi-flush) or a 4-24ANNMT backbox (surface only), ordered separately.

How many module spaces does it give?
24 spaces for common control and annunciation modules.

What fits inside with a 3-CAB14B?
Space for two 17 Ah batteries and two chassis assemblies providing 14 local rail module spaces.

Can the door hinge on either side?
Yes. The door may be mounted with hinges on the left or on the right.
