Edwards packages its EST3X life safety control platform as the 3X-SFS1R, a complete fire alarm control panel with user interface, CPU, one signaling loop, three option card slots and a universal 10 A power supply behind a red door. EST3X is aimed at mid- to large-sized buildings and can run standalone or networked with up to 64 nodes.
Key Features
- One Signature loop installed, with a second loop added by ordering the 3-SDC1 card
- Four built-in 3 A Class B notification/auxiliary circuits, synchronized to UL 1971
- Universal 110/220 V (94–264 VAC) 10 A power supply with patented Voltage Boost technology
- Large 24-line by 40-character backlit LCD with SpeedTouch rotary control
- Three option card slots for extra SLC loops, amplifiers or dialer/modem cards
- Form C alarm, supervisory and trouble relays; English-language interface
Specifications
-
Manufacturer: Edwards (EST)
-
Part Number: 3X-SFS1R
-
Door Color: Red
-
Language: English
-
Loops: 1 installed; 2nd loop requires 3-SDC1
-
Loop Capacity: 125 detectors and 125 single-address modules per SLC
-
NACs: 4 Class B, 3 A each
-
Power Supply: 94–264 VAC, 50/60 Hz, 10 A (UL)
-
Battery Charging: 65 Ah max.
-
Operating Environment: 32°F to 120°F (0°C to 49°C), 0–93% RH non-condensing
Compatibility
Works with Edwards Signature Series detectors and modules and supports up to 30 R-Series remote annunciators per node. Networks with other EST3X panels or an EST3 network of up to 64 nodes using optional 3X-NET or 3X-NET8 network cards.
FAQ
How many loops can the 3X-SFS1R support?
One Signature loop is installed and a 3-SDC1 card adds the second loop. The EST3X platform supports up to six intelligent analog loops and as many as 1,500 Signature Series devices per panel.
Can it be networked?
Yes. The optional 3X-NET8 card supports up to eight nodes, and the 3X-NET card is used for larger node counts or connection to EST3 systems. EST3X networks support up to 64 nodes over copper and/or fiber.
What batteries can it charge?
The built-in charger supports up to 65 Ah batteries.
Is the 3X-ETH1 needed?
The 3X-ETH1 is an optional Ethernet adapter that connects the system to the 3-SDU for remote programming and diagnostics.
