Edwards 3-RCC7R — EST3 remote closet enclosure, red wallbox and door, one chassis.
Remote closet cabinets exist so EST3 electronics can live in an electrical or telecom closet instead of a lobby. There is no viewing window: an optional display module mounts behind the door and is invisible with it shut. The 3-RCC7R is the single-chassis size, surface mounting, with a left-hand hinged door and red finish only.
- Room for one chassis assembly plus standby batteries
- Battery options: four 6V8A, two 12V10A, two 12V17A or two 12V50A
- Supplied as wallbox and door; ships at 37.5 lb (17 kg)
- Knockouts for 3/4 inch conduit; lag and keyway mounting holes
- Optional ATCK attack-rated door, UL Certified to a 2-minute rating, required for security applications
Chassis, power supply and rail modules are ordered separately. 65 Ah batteries require the 3-BATS shelf, which reduces chassis capacity by one — on a one-chassis 3-RCC7R that leaves none. If you need a viewing window, specify a 3-CAB lobby enclosure instead.
