Edwards 3-CAB7D — inner and outer door set for the EST3 3-CAB7B lobby wallbox, textured gray.
EST3 lobby enclosures are ordered as three separate items: the back box, the chassis assembly and the doors. The 3-CAB7D supplies the door half of that set for the 3-CAB7B, the wallbox that holds one chassis assembly with seven local rail module spaces. Edwards builds the outer door from #14 AWG cold rolled steel with the contoured EST3 profile and an integral viewing window, so modules stay visible with the cabinet closed and secure. Doors can be hung for right hand or left hand opening.
- Edwards catalog entry: inner and outer doors for the 3-CAB7B wallbox
- Outer door with integral viewing window, #14 AWG cold rolled steel, textured gray baked enamel
- Right or left hand hinging
- Ship weight 10 lb (4.5 kg)
- Red outer door is 3-CAB7DR; the EN 54 and CE version is 3-CAB7D-E
This is doors only: the 3-CAB7B wallbox and the chassis are ordered separately. Do not substitute 3-CAB14D or 3-CAB21D, which fit the taller two and three chassis wallboxes, and note the smaller 3-CAB5 already ships complete with its own door.
