Edwards 3-CAB7B — EST3 lobby enclosure wallbox with one chassis space.
EST3 lobby enclosures are split into back box, doors and chassis so the wallbox can be set and conduit run months before the electronics arrive. The 3-CAB7B is the single-chassis size: one chassis assembly plus the batteries underneath. Fitted with a 3-CHAS7 it yields seven local rail module spaces plus room for up to two power supplies and a footprint module. It semi-flush or surface mounts, so the same box suits a finished lobby wall or an equipment room.
- One chassis space; a 3-CHAS7 provides seven local rail module spaces
- Battery space for four 6 V 8 Ah, two 12 V 10 Ah or two 12 V 17 Ah
- #14 AWG cold rolled steel, black enamel finish
- Shipping weight 30 lb (13.6 kg)
Wallbox only — back boxes, doors and chassis ship separately. The doors are the 3-CAB7D set (inner and outer; 3-CAB7DR for a red outer door), and the chassis is separate again. For more capacity order the 3-CAB14B (two chassis) or 3-CAB21B (three).
Documents
FAQ
Does the 3-CAB7B include doors or a chassis?
No. It is the wallbox only. The inner and outer doors are the 3-CAB7D set (3-CAB7DR with a red outer door), and the chassis assembly is ordered separately.
What batteries fit in the 3-CAB7B?
Four 6 V 8 Ah, two 12 V 10 Ah, or two 12 V 17 Ah batteries.
How is it mounted?
The 3-CAB7 enclosure can be semi-flush or surface mounted, and it takes one chassis assembly providing seven local rail module spaces.
What if I need more space?
The 3-CAB14B wallbox takes two chassis and the 3-CAB21B three.
