Eaton Wheelock EL4XHS-FR — Eluxa outdoor horn strobe, NEMA type 4X, red housing with FIRE lettering and a clear lens.
The 4X body is the corrosion rated member of the Eluxa outdoor line, for parking structures, docks and building exteriors. It ships with a pre-wire capable back box, so the circuit can be run and tested before the appliance goes on.
- Six field-selectable clear lens candela settings, 15, 30, 75, 110, 150 and 185 cd
- Horn at 24 V: 90 dBA high, 86 dBA low, reverberant at 10 feet per UL 464
- Three horn patterns, continuous, T3 and T3/T4, at high or low output
- 16 to 33 VDC or FWR; 0.230 A at 185 cd with the horn on high
- NEMA type 4X and IP66 certified, tested to IP67, rated -40 to 150 °F
- LED in a Lexan lens, 1 Hz flash, 20 ms pulse; wall or ceiling mount, two-wire, 18 to 12 AWG
The suffix carries lettering first and color second: EL4XHS-FW is the same unit in white and EL4XHN-NR the horn alone, unlettered. EL3RHS-FR is the lighter NEMA 3R, IP54 equivalent and EL4XST-FR the strobe without the horn. Amber EL4XSTA-ALW runs a different set: 15, 30, 75, 95, 150 and 177 cd.
